- 12V DC constant voltage - Input voltage: 170-265V AC 50/60Hz - Output voltage: 12V DC - Short circuit; overload; over temperature protection - Ambient temp: -30 to 50 degreeC - Flex & plug included - Maximum recommeneded distance to light source: 10m
For CLA115011 / CLA1110011 / CLA1115011 and CLA112011 These drivers are manufactured with a split cable format for carrying increased current for easier connection of multiple loads
Note - Minimum load is 10% of rated power - Maximum load is 80% of rated power
Each driver can be used - At full load capacity by connecting all cables to one terminal block - With any combination of split cables (as long as the minimum and maximum loads below are adhered to) - To minimise the occurrence of voltage drops; the recommended maximum distance from the light source is 10m
